Technical Specifications
Output
Max Configurable Power (Watts): 600 Watts / 1.0kVA
Output Frequency (sync to mains): 50/60 Hz +/- 1 Hz Unsynchronized
Topology: Line interactive
Waveform type: Stepped approximation to a sinewave
Transfer Time: 6 ms typical : 10 ms maximum
Input
Input frequency: 50/60 Hz +/- 5 Hz Auto-sensing
Input voltage range for main operations: 170 – 280V
Number of Power Cords: 1
Batteries & Runtime
Communications & Management
Control panel: LED Status display with on line : on battery
Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating: 156Joules
Physical
Dimensions (W x H x D): 161 mm x 93 mm x 305 mm
Weight: 5.7 Kg
Color: Black
Environmental
Operating Temperature: 0 – 40 °C
Storage Temperature: -20 – 50 °C
